DT-201 Accessory
Factory-approved UV/IR handheld tester for safe, reliable flame detector verification.
Current Approvals
Specifications
- Factory-approved handheld UV/IR flame detector test source
- Emits steady-state UV and modulated IR at 4 Hz to simulate a typical fire signature
- Designed for use in hazardous locations
- Recommended for NFPA 72 required flame testing of Sierra detectors
- Typical test distance: approximately 3 to 8 feet on axis
- Enclosure: Copper-free cast aluminum with red epoxy finish
- Ratings: NEMA 4X, Explosion Proof; Class I Divisions I & II Groups B, C, D; Class II
- Divisions I & II Groups E, F, G; Class III
- Power supply: User-replaceable 9V battery
- Dimensions: 4.5″ x 4.8″ x 3.7″
Safe, Controlled Flame Simulation for Sierra Detectors
The DT-201 is a factory-approved handheld UV/IR test source designed to verify proper operation of Sierra flame detectors without using an open flame. It simulates the optical signature of a real fire, allowing technicians to confirm detector response safely and efficiently.
The DT-201 is commonly used with RED1 explosion-proof detectors, DCR1 corrosion-resistant models, and CFD indoor units. Whether the detector is installed in a refinery, semiconductor wet bench, or controlled industrial space, the DT-201 provides a consistent and repeatable way to confirm system functionality.
In environments where live fire testing is impractical, disruptive, or unsafe, the DT-201 becomes an essential commissioning and maintenance tool.
Designed for Hazardous Industrial Environments
Unlike generic light sources or improvised test methods, the DT-201 is engineered specifically for industrial flame detection systems. It emits a steady-state ultraviolet signal along with a modulated infrared signal at 4 Hz, replicating the spectral pattern of a typical fire.
Its explosion-proof, NEMA 4X rated enclosure allows it to be used in hazardous locations, making it suitable for oil and gas facilities, chemical plants, and other classified environments.
By using the DT-201, technicians can verify detector performance while maintaining compliance with NFPA 72 flame testing requirements.
